Toro Workman® MDX Utility Vehicle

Toro Workman® MDX Utility Vehicle

The Workman® MDX features the SRQ™ (Superior Ride Quality) system that delivers a more comfortable ride. The SRQ system on the Workman MDX model is made up of an independent A-frame front suspension, a swing-arm rear suspension and an active in-frame twister joint that dynamically connects the front and rear chassis. The Workman MDX features a durable plastic cargo bed with a load capacity of 1650 lbs (750 kg).

Quick Quote

Name(Required)

More Info

• Rugged injection-molded body styling. Latch opened hood design for ease of access for technicians.
• Extended front frame for additional leg room to enhance SRQ™ benefits of operator and passenger comfort.
• SRQ™ combines a coil-over shock absorber suspension design with the Active In-Frame™ twister joint.
• Double-walled composite bed can withstand the elements and heavy loads, and won't rust or dent.
• Allows each axle to react independently to the terrain. The result is the smoothest ride over the most undulating surfaces.
• Highest total payload capacities in their class for maximum productivity.

Specifications
Brakes - Front: Hydraulic Disc
Brakes - Rear: Hydraulic drum
Cargo Capacity: 1,250 lbs. (567 kg)
Cooling System: Liquid Cooled
Crated Model: Yes
Displacement: 600cc (36.6 ci)
Drivetrain: Diesel
Frame: Welded steel channel and tube in body construction. Frame surfaces are dipped e-coat. Body constructed of dent and corrosion resistant polypropylene.
Fuel / Power Source: Diesel
Fuel Capacity: 6.5 gallons (24.6 liters)
Gauges/Instrumentation: Hour meter, oil pressure, glow plug, coolant temperature, battery charge indicator lights and accessory power port. Dash has 2 cup holders, radio holder and glove box storage.
Ground Clearance: Front: 10" (25.4 cm) Rear: 7" (18 cm)
Height: Cab Installed: 79.2" (201.1 cm) Canopy Installed: 79.5" (201.9 cm)
Horn: Standard
Lights: Standard LED Headlights
Loader Arms: Yes
Optional Accessories: Canopy, fold-down windshield, electric bed lift, brush guard, ROPS, brake/tail/signal light kit, receiver hitch, BOSS plow
Power Steering: No
Power Train (Engine Description): 600 cc, liquid-cooled, 2-cylinder, Kubota® diesel. Biodiesel ready for use up to B-20 (20% biodiesel and 80% petroleum blend).
Product Length: 121.1" (307.5 cm)
Rear Draw Bar: Optional
Roll-Over Protection (ROPS): Optional
Seat: Bucket Seat
Starting: Pedal or Key Start
Steering System Description: Rack and pinion system with ergonomically positioned non-adjustable column. Steering wheel has 3 turns lock-to-lock and 17.2 to 1 ratio with a 13.75" (34.93 cm) diameter wheel.
Suspension - Front: Modified MacPherson Strut design with coil over shocks.
Suspension - Rear: Trailing arm with coil over shock absorbers.
Tires - Front: 22" x 9.5" - 10", 4-ply
Tires - Rear: 24" x 12" - 10", 4-ply. Optional All-Terrain Tire
Total Vehicle Capacity: 1,650 lbs. (750 kg)
Towing Capacity: 1,200 lbs. (544 kg)
Traction Drive (System): 2WD
Vehicle Configuration: Standard
Vehicle Type: Medium Duty
Wheelbase: 80.4" (204.2 cm)

Additional information

Fuel/Power Source

Vehicle Configuration

Traction Drive

The Workman® MDX features the SRQ™ (Superior Ride Quality) system that delivers a more comfortable ride. The SRQ system on the Workman MDX model is made up of an independent A-frame front suspension, a swing-arm rear suspension and an active in-frame twister joint that dynamically connects the front and rear chassis. The Workman MDX features a durable plastic cargo bed with a load capacity of 1650 lbs (750 kg).
