Toro Bullseye NuSurface™ 790 Fraise Mower

Toro Bullseye NuSurface™ 790 Fraise Mower

The Bullseye NuSurface™ 790 is used to fraise mow, flail mow, level, de-thatch, and renovate turf areas, as well as harvest sprigs. The NuSurface™ 790 is ideal for use on golf courses and sports fields and is quickly becoming the go-to grass removal tool for fast and efficient resurfacing projects. Its rotary action removes material and transfers it onto a conveyor system for disposal, leaving behind a smooth surface, immediately ready for sod or seeding. These machines are highly productive and can be adjusted in small increments for the desired level of aggressiveness. Rather than swapping out the entire blade mount rotor to change mowing operations, a cost effective optional Verti-Cut blade set is easily installed to replace the standard fraise/flail mowing blade set.

Quick Quote

Name(Required)

More Info

• 47" or 79" (119 or 200 cm)
• Verti-cut, flail mow or fraise mow and clean up in single pass.
• Simplifies blade changes and cleaning.
• Easily adjust depth and level machine on all four corners.
• Works with most trailers or dump boxes.
• Simple blade change to switch between fraise or flail mow and verti-cut.

Specification
3-Point Hitch: Category 2
Height: 45" (114.3 cm)
Hydraulic Connection: Two sets, double-acting valves
Length: 72" (182.8 cm)
Maximum Operating Depth (Working Depth): Up to 2" (50.8 mm)
Maximum PTO Speed: 540 RPM
Number of Blades: 76
Operating Speed: 1.8 mph (3.0 km/h)
Operating Width (Working Width): 79" (200 cm)
Optional Accessories: Set of Fraise/Flail Blades, Set of Verti-Cut Blades
Recommended Tow Vehicle Requirement: 40-50 hp (29.8-37.3 kW) with minimum 3,640 lbs. (1650 kg) lift capacity
Standard Items: PTO shaft, fraise/flail mow blade set
Verti-Cut Blade Spacing: 1, 2, 3 or 4" (2.5, 5, 7.5 or 10 cm)
Weight: 2,908 lbs. (1319 kg)
Width: 97" (246.3 cm)

Additional information

Operating Width

Series:

The Bullseye NuSurface™ 790 is used to fraise mow, flail mow, level, de-thatch, and renovate turf areas, as well as harvest sprigs. The NuSurface™ 790 is ideal for use on golf courses and sports fields and is quickly becoming the go-to grass removal tool for fast and efficient resurfacing projects. Its rotary action removes material and transfers it onto a conveyor system for disposal, leaving behind a smooth surface, immediately ready for sod or seeding. These machines are highly productive and can be adjusted in small increments for the desired level of aggressiveness. Rather than swapping out the entire blade mount rotor to change mowing operations, a cost effective optional Verti-Cut blade set is easily installed to replace the standard fraise/flail mowing blade set.
