Toro Groundsmaster® e3200

Toro Groundsmaster® e3200

The Next Groundsmaster eVolution. For 50 years, Toro has been creating innovative world-class out-front rotary mowers that deliver efficient productivity, exceptional reliability, and legendary cut quality. Toro proudly continues this legacy of industry leadership with the all-new lithium-ion battery powered Groundsmaster e3200 out-front rotary mower.

All-Day Power, All-Day Performance The all-new Groundsmaster e3200 can be configured with up to 17 HyperCell™ batteries for all-day runtime* in demanding conditions. Smart controls optimize power consumption by continuously and efficiently providing ample cutting power without bogging down. The reserve power mode allows the operator to set parameters ensuring enough battery power to return to the recharging station. The on-board 3.3kW charger allows for recharging overnight and ready to tackle another day.

Deck Options:

60” (152 cm) side discharge
60” (152 cm) rear discharge

Quick Quote

Name(Required)

More Info

• Expand and customize your power needs by adding additional HyperCell® lithium-ion batteries.
• Shares the same rugged chassis, commercial-grade mowing deck, and operator controls with our diesel-powered models.
• Operates significantly quieter for stealthy operation in noise sensitive applications and during early morning operation.
• Real-time information such as service reminders, alerts, and diagnostic information are delivered to the operator’s fingertips.
• Battery reserve power limit allows the operator to retain a specified amount of power and allowing them to return to the shop before the power level is too low.
• If the blades get bogged down, Smart Power adjusts their speed for proper cut.
• Allows the operator to slightly lift the deck, without fully raising, so the blades can stay engaged.
• Allows the supervisor to limit the unit's top speed within the InfoCenter™.
• Adjustable seating, tilt steering, easy access controls provide optimal operator comfort.
• Bullnose bumper, rugged spindles, and 7-gauge high strength steel decks are built for all mowing applications.
• Innovative tilt-up design makes maintenance and cleaning simple.
• Easily climb curbs and get to job sites other mowers simply can’t.
• Experience greater durability and longer life with this deck.
• Standard operator protection in the case of accidental rollovers and tipovers.

Specifications
Armrests: Standard
Battery: Toro HyperCell
Blade Style/Type: Rotary
Cab Unit: N/A
Cab Unit Description: N/A
Charger: On-board 100-240V, 12-16A, 3.3 kW charger
Controls: Key on/off, traction pedal, deck lift/lower, PTO, cruise control, emergency brake
Cup Holder: Standard
Cutting Unit Type/Configuration: 60” (152 cm) side and rear discharge options
Deck Construction: High-strength 7-gage steel with impact bumper, and side skids. Anti-scalp gauge wheels.
Drivetrain: Battery
Electrical System: 60 volt power for all systems, 12 volt for USB power plug and accessories
Fuel / Power Source: Battery
Gauges/Instrumentation: TDM display with alerts, hours and settings. Multiple languages.
Ground Clearance: 8” (20 cm) traction unit only
Ground Speed - Forward: 0 - 12.4 mph (0 - 20 km/h), customizable setting
Ground Speed - Reverse: 0 - 6.0 mph (0 - 10.0 km/h), customizable setting
Height: 79" (200 cm) with ROPS up
Height of Cut Range: 1” to 6” (25-152 mm) adjustable in 0.5” (12.7 mm) increments
Hydraulic Cylinders: Electric powered hydraulic cylinders control mowing deck lift/lower, weight transfer, and power steering functions
Hydraulic Fluid Capacity: 4.7 Gal. (17.8 L)
Hydraulic Fluid Type: Toro PX Extended Life Hydraulic Fluid
IntelliDash™ Capable: No
Interlocks: Operator presence switch, deck limit sensor, parking brake, emergency brake, traction neutral
Lighting: Optional
Main Frame/Chassis: All welded tubular and formed steel
Max Slope Angle: Refer to Operator’s Manual
Mowing Rate (Productivity): Up to 7.6 acres/hr (3.1 hectacres/hr) with 60" (152 cm) deck and max speed
Mowing Speed: 0 - 12.4 mph (0 - 20 km/h), customizable setting
Oil Capacity: 3.6 U.S. qt. (3.4 L)
Operator Area: Operator step, beverage holder, controls on right armrest
Optional Accessories: HyperCell Energy Expansion Kits, Recycler Kit, blade options, LED Work Light Kit, Road Light Kit, Operator Cooling Fan Kit, Sunshade Canopy, LED Beacon Kit for Sunshade
Overall Cutting Width: 60 in / 152 cm
Overall Width: 52" (132 cm)
Parking/Service Brakes: Dynamic braking with power regeneration, integrated automatic parking brake, emergency brake switch
Power Steering: Yes
Power Train (Engine Description): 11 HyperCell™ lithium-ion batteries standard, configurable with up to 17 for all-day runtime
Product Length: 107" (272 cm)
Seat: Deluxe bolstered seat with retractable seat belt
Spindle Assembly: Highly efficient internal permanent magnet (IPM) electric motors driving hardened steel blades
Starting: Key Start
Steering System Description: Power steering, tilt function
Tires - Front: 23" x 10.5" - 12", 4-ply, Turf Tire
Tires - Rear: 16" x 6.5" - 8", 4-ply, Turf Tire
Traction Drive: 2WD
Traction Drive (System): Electric 2-wheel traction drive transaxle
Weight: 2100 lbs. (952 kg) with standard 11 HyperCell batteries and charger
Wheelbase: 52" (132 cm)
Width of Cut: 60" (152 cm)

Additional information

Fuel/Power Source

Width of Cut

Series:

The Next Groundsmaster eVolution. For 50 years, Toro has been creating innovative world-class out-front rotary mowers that deliver efficient productivity, exceptional reliability, and legendary cut quality. Toro proudly continues this legacy of industry leadership with the all-new lithium-ion battery powered Groundsmaster e3200 out-front rotary mower.

All-Day Power, All-Day Performance The all-new Groundsmaster e3200 can be configured with up to 17 HyperCell™ batteries for all-day runtime* in demanding conditions. Smart controls optimize power consumption by continuously and efficiently providing ample cutting power without bogging down. The reserve power mode allows the operator to set parameters ensuring enough battery power to return to the recharging station. The on-board 3.3kW charger allows for recharging overnight and ready to tackle another day.

Deck Options:

60” (152 cm) side discharge
60” (152 cm) rear discharge
