Toro PROLINE™ HDX 48 in. (122 cm) Mid-Size Mower (50-State Model)

Toro PROLINE™ HDX 48 in. (122 cm) Mid-Size Mower (50-State Model)

Contractors know every second not mowing is a lost opportunity, and training your crew on new equipment can cause unnecessary setbacks in time and money. Maximize your efficiency with the Toro Mid-Size ProLine mowers. Not only will your crew be mowing in no time with easy-to-learn controls, but you’ll also enjoy top-line reliability and professional cutting performance. You’ll love the convenience of the 2-wheel sulky, which rotates 360 degrees and simply folds away when not in use; no more attaching and removing when trailering! And you can rest easy knowing that Toro stands behind its mowers with a 3-year, 750-hour warranty. And as a Toro owner, you’ll have access to nearly 3,000 servicing dealers across the U.S. and Canada ready to assist you. Count on it.

Quick Quote

Name(Required)

More Info

• Made to Last - Your Toro is also built to take on years of rough rides with a bull nose bumper, 7/10-gauge deck, rubber discharge chute and 20" wheels with curb clearance.
• Quick Adjustment - Changing cut lengths on the go is a snap with a single-point height of cut adjustment.
• Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.

Specifications:
Anti Scalp Wheels: Standard
Blade Tip Speed: 18,500 ft/min / 5,638 m/min
Box Dimensions: 82 in. x 63 in. x 52.5 in. / 208.3 cm x 160.0 cm x 133.4 cm
CARB Compliant: CARB Compliant
Caster Tires: 11 in. x 4 in. - 5 in. (27.9 cm x 10 cm - 12.7 cm); Smooth
Deck Design: 4.5” (11.43 cm) deck depth, 48" (122 cm) 7/10-Gauge High-Strength Steel
Deck Material: 7/10 Gauge High-Strength Steel
Deck Size: 48 in / 122 cm
Discharge Chute: Rubber
Drive Tires: 20 in. x 9.5 in. - 8 in. (50.8 cm x 24 cm - 20.3 cm)
Engine: 22 HP* Kawasaki® FX
Engine Brand: Kawasaki
Engine Displacement (cc): 726 cc
Engine Horsepower: 22.0 hp
Forward Mowing Speed: Up to 7.0 mph / 11.2 kph
Front Bumper: Reinforced Bull-Nose
Fuel Capacity: 5 gal. / 18.9 L / 20 Qt.
Fuel Type: Gasoline
Height of Cut: 1.5 - 4.5 in. / 3.8 - 11.4 cm
Number of Blades: 3
Product Type: Walk Behind Mowers
Product Use: Commercial
Reverse Mowing Speed: Up to 3.0 mph / 4.8 kph
Spindle Bearings: Maintenance-free
Spindle Housing: 8 in / 20.3 cm Cast Aluminum
Start Type: Electric
Steering Controls: Twin Lever
Transmission: Hydro-Gear ZT-3100 135-0139

Additional information

Fuel Type

Deck Width

Is CARB Compliant?

Series:

Contractors know every second not mowing is a lost opportunity, and training your crew on new equipment can cause unnecessary setbacks in time and money. Maximize your efficiency with the Toro Mid-Size ProLine mowers. Not only will your crew be mowing in no time with easy-to-learn controls, but you’ll also enjoy top-line reliability and professional cutting performance. You’ll love the convenience of the 2-wheel sulky, which rotates 360 degrees and simply folds away when not in use; no more attaching and removing when trailering! And you can rest easy knowing that Toro stands behind its mowers with a 3-year, 750-hour warranty. And as a Toro owner, you’ll have access to nearly 3,000 servicing dealers across the U.S. and Canada ready to assist you. Count on it.
