Toro Reelmaster® 7000

Toro Reelmaster® 7000

The Toro® Reelmaster® 7000-D is equipped with a powerful 55 hp (41kW) Yanmar® diesel engine and a SmartCool™ temperature-activated, auto-reversing fan that automatically blows debris off the air intake screen to keep the engine cool. High-torque reel motors allow the Reelmaster 7000-D to power through tough scalping and verticutting jobs, resulting in high productivity. This product also features Toro’s industry leading EdgeSeries™ dual precision adjustment (DPA) cutting units. Available in 27 inch or 32 inch width. Optional standard air-ride suspension and an ergonomic control arm keeps operators comfortable and productive.

Quick Quote

Name(Required)

More Info

• The Reelmaster 7000-D is powered by a 55 hp (41kW) Yanmar® diesel engine that includes an exhaust after-treatment system that ensures machine emissions meet the EPA requirements and that your course can do its part for the environment.
• Variable speed, temperature actuated reversing fan. Blows chaff off intake screen to help reduce overheating. Big time saver which reduces that amount of times an operator has to stop and exit the unit to clean the back hood.
• The Reelmaster 7000 features a unique, parallel hydraulic traction system that assures full-time, bi-directional 4-wheel drive. Parallel hydraulic flow between front and rear wheels means that you will have 4-wheel drive assistance in turns, enabling easier trimming around objects without tire scuffing and dependable traction on hills and wet terrain. Optional 4WD Flow Divider Kit.
• By adding two 32" (81 cm) rear cutting units the overlap area can be increased to almost 6" (15 cm) thus eliminating the possibility of uncut grass in tight turns or on hillsides.
• Improved access to routine service points and service components, along with a robust machine design, results in less frequent maintenance intervals and less time is required to perform maintenance tasks.
• All of the indicators and controls to operate the unit are conveniently located on the right armrest. Control console pivots back for right hand entry and exit. Tilt steering, deluxe suspension seat, improved visibility and lower operating noise enhance the operator experience and help to reduce fatigue.
• Dual Precision Adjustment (DPA) cutting units – featuring Toro’s EdgeSeries™ reels combine to deliver a consistent, high quality cut and superior after cut appearance, while reducing maintenance with improved reel edge retention.

Specifications
Air Filter: Dry, replaceable primary and safety elements.
Armrests: Standard
Battery: 12V
Bedknife Adjustment: Dual Precision Adjustment (DPA), bedknife to reel.
Blade Style/Type: Reel
Blade Type (Description): EdgeSeries™ DPA radial reels.
Cab Unit: N/A
Clip Frequency/Backlapping: Manually controlled, variable reel speed for control of clip frequency. Reel speeds are incrementally adjustable between 200 - 1,650 rpm with a backlap speed of 200 rpm.
Controls: Ignition switch, LED headlight switch, hand-operated throttle, foot-operated traction pedal, joystick for cutting unit lift, mow/transport selector switch, lockable individual brake pedals, park brake.
Cooling System Description: 9 row single pass cooler with tilt out for cleaning. Variable speed hydraulic fan drive with automatic (based on coolant and oil temps) and manual reversing capabilities. Rear-mount aluminum radiator (6 fins per inch, 9 quart (8.5 liters) capacity).
Cup Holder: Standard
Cutting Unit Accessories: Rear Roller Brush Kit, Universal Groomer, Broomer
Cutting Unit Lift/Lower: Hydraulic - front and rear cutting unit lift/lower are sequenced for uniform starting and ending points.
Cutting Unit Type/Configuration: Hydraulically driven, with adjustable rear weight transfer spring. Interchangeable to all positions with rear throw capability.
Drivetrain: Diesel
Electrical System: 12-volt, 650 CCA battery, 80 amp alternator. Overload protection with automotive type fuses.
Engine Cooling: Liquid Cooled
Fuel / Power Source: Diesel / Biodiesel
Fuel Capacity: 22 U.S. gal. (83 L)
Fuel Filter: Spin-on fuel filter.
Gauges/Instrumentation: InfoCenter™: Onboard LCD display shows alerts, faults, service reminders, electrical systems diagnostics, coolant temp., low oil pressure, alternator, engine hours, engine rpm, voltage, reel speed, backlap speed, glow indicator, lift/lower indicator.
Ground Speed - Forward: 0 - 14 mph (0 - 22.5 km/h)
Ground Speed - Reverse: 0 - 7 mph (0 - 11 km/h)
Height: 87" (220 cm)
Height of Cut Range: 8-Blade: 0.5" - 2.5" (13 mm - 64 mm)
11-Blade: 0.25" - 0.75" (6 mm - 19 mm)
Hydraulic Fluid Capacity: 8.25 U.S. gal. (31.3 L)
Hydraulic Fluid Type: Toro PX™ Extended Life Hydraulic Fluid
IntelliDash™ Capable: Yes
Interlocks: Starting, operator presence, mowing, transport and parking brake.
Lighting: Standard
Main Frame/Chassis: All welded formed-steel frame with integral tie-down anchors.
Max Slope Angle: Refer to operator's manual.
Mowing Speed: 0 - 7 mph (0 - 11 km/h)
Number of Blades: 11, 8
Oil Capacity: 6 U.S. qt. (5.7 L)
Oil Cooler Description: Aluminum side-mounted cooler. Variable speed hydraulic fan drive with automatic (based on coolant and oil temps) and manual reversing capabilities
Optional Accessories: Sunshade (with optional operator cooling fan, LED work lights, rotating amber beacon), 2-post ROPS Extension Kit (with optional windshield, operator cooling fan, LED work lights, rotating amber beacon and safety and security cage)
Overall Width: 121" (307 cm) with 27" cutting units, 126" (320 cm) with 32" cutting units
Parking/Service Brakes: Mechanically actuated, internal wet disc brakes. Individual foot-operated steering brake control of left and right wheel or lock pedals together.
Power Steering: Yes
Power Train (Engine Description): Yanmar® 4-cylinder, liquid-cooled diesel engine, 55 hp (41 kW). Tier IV compliant.
Product Length: 136" (345 cm) with 27" cutting units, 141" (358 cm) with 32" cutting units
Reel Diameter: 7 in. (17.8cm)
Reel/Cylinder Drive: Hydraulic
Rollers: 3" (7.6 cm) diameter, deep groove plastic front Wiehle roller. 3.0" (7.6 cm) diameter steel rear roller (other roller configurations optional).
Safety/Operator Safety: 2-post ROPS and retractable seat belts standard.
Seat: Premium air ride suspension seat with full range of adjustments; retractable seat belt.
Starting: Switch
Steering System Description: Power steering with dedicated power source, tilt steering.
Tires - Front: 31" x 13.5" - 15", 4-ply, Turf Tire
Tires - Rear: 0" x 12" - 10", 4-ply, Turf Tread
Traction Drive: 4WD
Traction Drive (System): Full-time, bi-directional, hydrostatic, closed-loop, 4WD transmission. Optional 4WD Flow Divider Kit.
Transport Width: 94" (239 cm)
Turning Circle (Diameter): 119" (302.3 cm) transport
Weight: 4,300 lbs. (1950 kg) - with full fluids, no cutting units.
Width of Cut: 121" (307 cm) or 126" (320 cm)
